10 products found

Categories
Capacitance (µF)
Tolerance
KVAR
  • N/A
Voltage AC
Voltage DC
ESR
  • N/A
Application
Operating Temperature
Product Code Image Data Sheet Attributes
X300 19 10 200 round film capacitor for power supply and power current

Data Sheet: X300

  • Application: Power Supply
  • Capacitance (µF): 19
  • Tolerance: ±10%
  • Voltage Rating - DC: 200V
  • Voltage Rating - AC:
  • Operating Temperature: -55 °C to +85 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Self-Encased w/ PP or PE
  • Termination: Solid Wire
  • Dimension inches: 1.574" H x 1.450" D
  • Dimension mm: 40.0mm x 36.8mm
X300 19 20 200 round film capacitor for power supply and power current

Data Sheet: X300

  • Application: Power Supply
  • Capacitance (µF): 19
  • Tolerance: ±20%
  • Voltage Rating - DC: 200V
  • Voltage Rating - AC:
  • Operating Temperature: -55 °C to +85 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Self-Encased w/ PP or PE
  • Termination: Solid Wire
  • Dimension inches: 1.574" H x 1.450" D
  • Dimension mm: 40.0mm x 36.8mm
X300 19 5 200 round film capacitor for power supply and power current

Data Sheet: X300

  • Application: Power Supply
  • Capacitance (µF): 19
  • Tolerance: ±5%
  • Voltage Rating - DC: 200V
  • Voltage Rating - AC:
  • Operating Temperature: -55 °C to +85 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Self-Encased w/ PP or PE
  • Termination: Solid Wire
  • Dimension inches: 1.574" H x 1.450" D
  • Dimension mm: 40.0mm x 36.8mm
X345 19 10 220

Data Sheet: X345

  • Application: DC Filter, Sample Hold
  • Capacitance (µF): 19
  • Tolerance: ±10%
  • Voltage Rating - AC: 220V
  • Operating Temperature: -25 °C to +75 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound combination of metallized polypropylene and polyester
  • Dielectric Material: Polypropylene – Metallized and Polyester
  • Case: Preformed Case with Epoxy Fill
  • Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE
  • Dimension inches: 1.142" T x 1.614" H x 2.283" W
  • Dimension mm: 29.0mm x 41.0mm x 58.0mm
X345 19 5 220

Data Sheet: X345

  • Application: DC Filter, Sample Hold
  • Capacitance (µF): 19
  • Tolerance: ±5%
  • Voltage Rating - AC: 220V
  • Operating Temperature: -25 °C to +75 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound combination of metallized polypropylene and polyester
  • Dielectric Material: Polypropylene – Metallized and Polyester
  • Case: Preformed Case with Epoxy Fill
  • Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE
  • Dimension inches: 1.142" T x 1.614" H x 2.283" W
  • Dimension mm: 29.0mm x 41.0mm x 58.0mm
X347 19 10 100 / 250

Data Sheet: X347

  • Application: DC Filter, Sample Hold
  • Capacitance (µF): 19
  • Tolerance: ±10%
  • Voltage Rating - AC: 100V / 250V
  • Operating Temperature: -25 °C to +85 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene – Metallized
  • Case: Preformed Case with Epoxy Fill
  • Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE
  • Dimension inches: 1.142" T x 1.614" H x 2.283" W
  • Dimension mm: 29.0mm x 41.0mm x 58.0mm
X347 19 5 100 / 250

Data Sheet: X347

  • Application: DC Filter, Sample Hold
  • Capacitance (µF): 19
  • Tolerance: ±5%
  • Voltage Rating - AC: 100V / 250V
  • Operating Temperature: -25 °C to +85 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene – Metallized
  • Case: Preformed Case with Epoxy Fill
  • Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE
  • Dimension inches: 1.142" T x 1.614" H x 2.283" W
  • Dimension mm: 29.0mm x 41.0mm x 58.0mm
X637 19 10 220 flat film capacitor for power supply and power current

Data Sheet: X637

  • Application: Power Supply, Pulse Current
  • Capacitance (µF): 19
  • Tolerance: ±10%
  • Voltage Rating - AC: 220V
  • Operating Temperature: -55 °C to +85 °C
  • IPeak: 32.3
  • Lifecycle @ Rated Temp & Voltage: 30,000 hrs
  • Construction: non-inductive wound metallized polyester film
  • Dielectric Material: Polyester – Metallized
  • Case: Tape Wrap and Epoxy Fill
  • Termination: Solid Wire
  • Dimension inches: 0.755" T x 2.624" H x 1.126" L
  • Dimension mm: 19.2mm x 2.624" x 28.6mm
X637 19 20 220 flat film capacitor for power supply and power current

Data Sheet: X637

  • Application: Power Supply, Pulse Current
  • Capacitance (µF): 19
  • Tolerance: ±20%
  • Voltage Rating - AC: 220V
  • Operating Temperature: -55 °C to +85 °C
  • IPeak: 32.3
  • Lifecycle @ Rated Temp & Voltage: 30,000 hrs
  • Construction: non-inductive wound metallized polyester film
  • Dielectric Material: Polyester – Metallized
  • Case: Tape Wrap and Epoxy Fill
  • Termination: Solid Wire
  • Dimension inches: 0.755" T x 2.624" H x 1.126" L
  • Dimension mm: 19.2mm x 2.624" x 28.6mm
X637 19 5 220 flat film capacitor for power supply and power current

Data Sheet: X637

  • Application: Power Supply, Pulse Current
  • Capacitance (µF): 19
  • Tolerance: ±5%
  • Voltage Rating - AC: 220V
  • Operating Temperature: -55 °C to +85 °C
  • IPeak: 32.3
  • Lifecycle @ Rated Temp & Voltage: 30,000 hrs
  • Construction: non-inductive wound metallized polyester film
  • Dielectric Material: Polyester – Metallized
  • Case: Tape Wrap and Epoxy Fill
  • Termination: Solid Wire
  • Dimension inches: 0.755" T x 2.624" H x 1.126" L
  • Dimension mm: 19.2mm x 2.624" x 28.6mm
Product Code Image Data Sheet Attributes
X300 19 10 200 round film capacitor for power supply and power current

Data Sheet: X300

  • Application: Power Supply
  • Capacitance (µF): 19
  • Tolerance: ±10%
  • Voltage Rating - DC: 200V
  • Voltage Rating - AC:
  • Operating Temperature: -55 °C to +85 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Self-Encased w/ PP or PE
  • Termination: Solid Wire
  • Dimension inches: 1.574" H x 1.450" D
  • Dimension mm: 40.0mm x 36.8mm
X300 19 20 200 round film capacitor for power supply and power current

Data Sheet: X300

  • Application: Power Supply
  • Capacitance (µF): 19
  • Tolerance: ±20%
  • Voltage Rating - DC: 200V
  • Voltage Rating - AC:
  • Operating Temperature: -55 °C to +85 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Self-Encased w/ PP or PE
  • Termination: Solid Wire
  • Dimension inches: 1.574" H x 1.450" D
  • Dimension mm: 40.0mm x 36.8mm
X300 19 5 200 round film capacitor for power supply and power current

Data Sheet: X300

  • Application: Power Supply
  • Capacitance (µF): 19
  • Tolerance: ±5%
  • Voltage Rating - DC: 200V
  • Voltage Rating - AC:
  • Operating Temperature: -55 °C to +85 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Self-Encased w/ PP or PE
  • Termination: Solid Wire
  • Dimension inches: 1.574" H x 1.450" D
  • Dimension mm: 40.0mm x 36.8mm
X345 19 10 220

Data Sheet: X345

  • Application: DC Filter, Sample Hold
  • Capacitance (µF): 19
  • Tolerance: ±10%
  • Voltage Rating - AC: 220V
  • Operating Temperature: -25 °C to +75 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound combination of metallized polypropylene and polyester
  • Dielectric Material: Polypropylene – Metallized and Polyester
  • Case: Preformed Case with Epoxy Fill
  • Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE
  • Dimension inches: 1.142" T x 1.614" H x 2.283" W
  • Dimension mm: 29.0mm x 41.0mm x 58.0mm
X345 19 5 220

Data Sheet: X345

  • Application: DC Filter, Sample Hold
  • Capacitance (µF): 19
  • Tolerance: ±5%
  • Voltage Rating - AC: 220V
  • Operating Temperature: -25 °C to +75 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound combination of metallized polypropylene and polyester
  • Dielectric Material: Polypropylene – Metallized and Polyester
  • Case: Preformed Case with Epoxy Fill
  • Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE
  • Dimension inches: 1.142" T x 1.614" H x 2.283" W
  • Dimension mm: 29.0mm x 41.0mm x 58.0mm
X347 19 10 100 / 250

Data Sheet: X347

  • Application: DC Filter, Sample Hold
  • Capacitance (µF): 19
  • Tolerance: ±10%
  • Voltage Rating - AC: 100V / 250V
  • Operating Temperature: -25 °C to +85 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene – Metallized
  • Case: Preformed Case with Epoxy Fill
  • Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE
  • Dimension inches: 1.142" T x 1.614" H x 2.283" W
  • Dimension mm: 29.0mm x 41.0mm x 58.0mm
X347 19 5 100 / 250

Data Sheet: X347

  • Application: DC Filter, Sample Hold
  • Capacitance (µF): 19
  • Tolerance: ±5%
  • Voltage Rating - AC: 100V / 250V
  • Operating Temperature: -25 °C to +85 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene – Metallized
  • Case: Preformed Case with Epoxy Fill
  • Termination: AMP187, AMP250, SOLID WIRE, DIN SOLDER TABS, AND STRANDED WIRE
  • Dimension inches: 1.142" T x 1.614" H x 2.283" W
  • Dimension mm: 29.0mm x 41.0mm x 58.0mm
X637 19 10 220 flat film capacitor for power supply and power current

Data Sheet: X637

  • Application: Power Supply, Pulse Current
  • Capacitance (µF): 19
  • Tolerance: ±10%
  • Voltage Rating - AC: 220V
  • Operating Temperature: -55 °C to +85 °C
  • IPeak: 32.3
  • Lifecycle @ Rated Temp & Voltage: 30,000 hrs
  • Construction: non-inductive wound metallized polyester film
  • Dielectric Material: Polyester – Metallized
  • Case: Tape Wrap and Epoxy Fill
  • Termination: Solid Wire
  • Dimension inches: 0.755" T x 2.624" H x 1.126" L
  • Dimension mm: 19.2mm x 2.624" x 28.6mm
X637 19 20 220 flat film capacitor for power supply and power current

Data Sheet: X637

  • Application: Power Supply, Pulse Current
  • Capacitance (µF): 19
  • Tolerance: ±20%
  • Voltage Rating - AC: 220V
  • Operating Temperature: -55 °C to +85 °C
  • IPeak: 32.3
  • Lifecycle @ Rated Temp & Voltage: 30,000 hrs
  • Construction: non-inductive wound metallized polyester film
  • Dielectric Material: Polyester – Metallized
  • Case: Tape Wrap and Epoxy Fill
  • Termination: Solid Wire
  • Dimension inches: 0.755" T x 2.624" H x 1.126" L
  • Dimension mm: 19.2mm x 2.624" x 28.6mm
X637 19 5 220 flat film capacitor for power supply and power current

Data Sheet: X637

  • Application: Power Supply, Pulse Current
  • Capacitance (µF): 19
  • Tolerance: ±5%
  • Voltage Rating - AC: 220V
  • Operating Temperature: -55 °C to +85 °C
  • IPeak: 32.3
  • Lifecycle @ Rated Temp & Voltage: 30,000 hrs
  • Construction: non-inductive wound metallized polyester film
  • Dielectric Material: Polyester – Metallized
  • Case: Tape Wrap and Epoxy Fill
  • Termination: Solid Wire
  • Dimension inches: 0.755" T x 2.624" H x 1.126" L
  • Dimension mm: 19.2mm x 2.624" x 28.6mm

Showing all 10 results

Cannot find the part you're looking for? Click here!

×

Inquire About

Product Inquiry
Name
Name
First Name
Last Name
