Product Code Image Data Sheet Attributes
WME-RS 10 6 260 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 10
  • Tolerance: ±6%
  • Voltage Rating - AC: 260V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 2.953" H x 1.595" D
  • Dimension mm: 75.0mm x 40.5mm
WME-RS 10 6 400 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 10
  • Tolerance: ±6%
  • Voltage Rating - AC: 400V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 2.953" H x 1.595" D
  • Dimension mm: 75.0mm x 40.5mm
WME-RS 10 6 450 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 10
  • Tolerance: ±6%
  • Voltage Rating - AC: 450V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 2.953" H x 1.595" D
  • Dimension mm: 75.0mm x 40.5mm
WME-RS 12 6 260 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 12
  • Tolerance: ±6%
  • Voltage Rating - AC: 260V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 2.953" H x 1.595" D
  • Dimension mm: 75.0mm x 40.5mm
WME-RS 12 6 400 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 12
  • Tolerance: ±6%
  • Voltage Rating - AC: 400V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 3.937" H x 1.595" D
  • Dimension mm: 100.0mm x 40.5mm
WME-RS 12 6 450 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 12
  • Tolerance: ±6%
  • Voltage Rating - AC: 450V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 3.937" H x 1.595" D
  • Dimension mm: 100.0mm x 40.5mm
WME-RS 14 6 260 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 14
  • Tolerance: ±6%
  • Voltage Rating - AC: 260V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 2.953" H x 1.595" D
  • Dimension mm: 75.0mm x 40.5mm
WME-RS 14 6 400 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 14
  • Tolerance: ±6%
  • Voltage Rating - AC: 400V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 3.937" H x 1.595" D
  • Dimension mm: 100.0mm x 40.5mm
WME-RS 14 6 450 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 14
  • Tolerance: ±6%
  • Voltage Rating - AC: 450V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 3.937" H x 1.595" D
  • Dimension mm: 100.0mm x 40.5mm
WME-RS 15 6 260 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 15
  • Tolerance: ±6%
  • Voltage Rating - AC: 260V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 2.953" H x 1.595" D
  • Dimension mm: 75.0mm x 40.5mm
WME-RS 15 6 400 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 15
  • Tolerance: ±6%
  • Voltage Rating - AC: 400V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 3.937" H x 1.595" D
  • Dimension mm: 100.0mm x 40.5mm
WME-RS 15 6 450 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 15
  • Tolerance: ±6%
  • Voltage Rating - AC: 450V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 3.937" H x 1.595" D
  • Dimension mm: 100.0mm x 40.5mm
WME-RS 16 6 260 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 16
  • Tolerance: ±6%
  • Voltage Rating - AC: 260V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 2.953" H x 1.595" D
  • Dimension mm: 75.0mm x 40.5mm
WME-RS 16 6 400 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 16
  • Tolerance: ±6%
  • Voltage Rating - AC: 400V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 3.937" H x 1.595" D
  • Dimension mm: 100.0mm x 40.5mm
WME-RS 16 6 450 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 16
  • Tolerance: ±6%
  • Voltage Rating - AC: 450V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 3.937" H x 1.595" D
  • Dimension mm: 100.0mm x 40.5mm
WME-RS 18 6 260 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 18
  • Tolerance: ±6%
  • Voltage Rating - AC: 260V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 2.953" H x 1.595" D
  • Dimension mm: 75.0mm x 40.5mm
WME-RS 18 6 400 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 18
  • Tolerance: ±6%
  • Voltage Rating - AC: 400V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 3.937" H x 1.595" D
  • Dimension mm: 100.0mm x 40.5mm
WME-RS 18 6 450 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 18
  • Tolerance: ±6%
  • Voltage Rating - AC: 450V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 3.937" H x 1.760" D
  • Dimension mm: 100.0mm x 44.7mm
WME-RS 20 6 260 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 20
  • Tolerance: ±6%
  • Voltage Rating - AC: 260V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 3.937" H x 1.595" D
  • Dimension mm: 100.0mm x 40.5mm
WME-RS 20 6 400 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 20
  • Tolerance: ±6%
  • Voltage Rating - AC: 400V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 3.937" H x 1.760" D
  • Dimension mm: 100.0mm x 44.7mm
Product Code Image Data Sheet Attributes
WME-RS 10 6 260 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 10
  • Tolerance: ±6%
  • Voltage Rating - AC: 260V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 2.953" H x 1.595" D
  • Dimension mm: 75.0mm x 40.5mm
WME-RS 10 6 400 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 10
  • Tolerance: ±6%
  • Voltage Rating - AC: 400V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 2.953" H x 1.595" D
  • Dimension mm: 75.0mm x 40.5mm
WME-RS 10 6 450 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 10
  • Tolerance: ±6%
  • Voltage Rating - AC: 450V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 2.953" H x 1.595" D
  • Dimension mm: 75.0mm x 40.5mm
WME-RS 12 6 260 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 12
  • Tolerance: ±6%
  • Voltage Rating - AC: 260V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 2.953" H x 1.595" D
  • Dimension mm: 75.0mm x 40.5mm
WME-RS 12 6 400 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 12
  • Tolerance: ±6%
  • Voltage Rating - AC: 400V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 3.937" H x 1.595" D
  • Dimension mm: 100.0mm x 40.5mm
WME-RS 12 6 450 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 12
  • Tolerance: ±6%
  • Voltage Rating - AC: 450V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 3.937" H x 1.595" D
  • Dimension mm: 100.0mm x 40.5mm
WME-RS 14 6 260 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 14
  • Tolerance: ±6%
  • Voltage Rating - AC: 260V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 2.953" H x 1.595" D
  • Dimension mm: 75.0mm x 40.5mm
WME-RS 14 6 400 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 14
  • Tolerance: ±6%
  • Voltage Rating - AC: 400V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 3.937" H x 1.595" D
  • Dimension mm: 100.0mm x 40.5mm
WME-RS 14 6 450 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 14
  • Tolerance: ±6%
  • Voltage Rating - AC: 450V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 3.937" H x 1.595" D
  • Dimension mm: 100.0mm x 40.5mm
WME-RS 15 6 260 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 15
  • Tolerance: ±6%
  • Voltage Rating - AC: 260V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 2.953" H x 1.595" D
  • Dimension mm: 75.0mm x 40.5mm
WME-RS 15 6 400 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 15
  • Tolerance: ±6%
  • Voltage Rating - AC: 400V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 3.937" H x 1.595" D
  • Dimension mm: 100.0mm x 40.5mm
WME-RS 15 6 450 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 15
  • Tolerance: ±6%
  • Voltage Rating - AC: 450V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 3.937" H x 1.595" D
  • Dimension mm: 100.0mm x 40.5mm
WME-RS 16 6 260 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 16
  • Tolerance: ±6%
  • Voltage Rating - AC: 260V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 2.953" H x 1.595" D
  • Dimension mm: 75.0mm x 40.5mm
WME-RS 16 6 400 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 16
  • Tolerance: ±6%
  • Voltage Rating - AC: 400V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 3.937" H x 1.595" D
  • Dimension mm: 100.0mm x 40.5mm
WME-RS 16 6 450 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 16
  • Tolerance: ±6%
  • Voltage Rating - AC: 450V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 3.937" H x 1.595" D
  • Dimension mm: 100.0mm x 40.5mm
WME-RS 18 6 260 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 18
  • Tolerance: ±6%
  • Voltage Rating - AC: 260V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 2.953" H x 1.595" D
  • Dimension mm: 75.0mm x 40.5mm
WME-RS 18 6 400 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 18
  • Tolerance: ±6%
  • Voltage Rating - AC: 400V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 3.937" H x 1.595" D
  • Dimension mm: 100.0mm x 40.5mm
WME-RS 18 6 450 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 18
  • Tolerance: ±6%
  • Voltage Rating - AC: 450V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 3.937" H x 1.760" D
  • Dimension mm: 100.0mm x 44.7mm
WME-RS 20 6 260 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 20
  • Tolerance: ±6%
  • Voltage Rating - AC: 260V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 3.937" H x 1.595" D
  • Dimension mm: 100.0mm x 40.5mm
WME-RS 20 6 400 round oil filled capacitor for motor run, lighting and filtering

Data Sheet: WME-RS

  • Application: Filtering, Lighting, Motor Run
  • Capacitance (µF): 20
  • Tolerance: ±6%
  • Voltage Rating - AC: 400V
  • Operating Temperature: -40 °C to +80 °C
  • Lifecycle @ Rated Temp & Voltage: 60,000 hrs
  • Construction: non-inductive wound metallized polypropylene film
  • Dielectric Material: Polypropylene - Metallized
  • Case: Seamless Can
  • Termination: 2-Tine, Quick Disconnect
  • Dimension inches: 3.937" H x 1.760" D
  • Dimension mm: 100.0mm x 44.7mm

Showing 1–20 of 415 results

Cannot find the part you're looking for? Click here!

×

Inquire About

Product Inquiry
Name
Name
First Name
Last Name
